Pyramid Apex 7600-DB1 Bill Acceptor (12V, $1–$100)

12V Apex for $1–$100 notes under the DB1 part number, fully interchangeable with the 7600-UB1.

Pyramid Apex 7600-DB1 Bill Acceptor (12V, $1–$100)

Service paperwork, machine manuals and older purchase orders often call for a 7600-DB1 by name, so we list it under that exact part number. Pyramid has confirmed there is no operational difference between the 7600-DB1 and the 7600-UB1, which means either one can go into a machine that specified the other. The DB1 runs on 12VDC from the host harness, reads US notes from $1 through $100 with its magnetic-head reader, and holds 500 notes. Its model number, 7600, ends in 00, which the Apex 7000 manual we host defines as Pyramid's standard bezel. Setup is by DIP switches or PC, calibration is automatic, and dual-stage optical anti-stringing comes standard. Pick whichever part number matches your records; the price is the same.

Key features

  • Accepts US $1, $5, $10, $20, $50 and $100 notes (7600 wide-denomination series)
  • 12VDC operation — powered directly from the game or kiosk harness
  • Standard Pyramid bezel with lighted bill-entry arrows
  • 500-note non-locking stacker included
  • Bill acceptance rate greater than 95%; processes up to 20 bills per minute
  • Dual-stage optical anti-stringing technology with enhanced magnetic sensing
  • Automatic self-calibration — no manual adjustment required
  • DIP-switch and PC configuration; flash firmware updates via PRO-2, BluStream or USB cable
  • Made in the USA — designed for 20+ years of field reliability

Specifications

Model / SKU7600-DB1
Denominations$1 – $100 (USD)
Power / interface12VDC
BezelStandard Pyramid bezel
Acceptance rateGreater than 95%
SpeedUp to 20 bills per minute
Maximum bill width72mm
Stacker500-note non-locking stacker
SecurityDual-stage optical anti-stringing + enhanced magnetic sensing
CalibrationAutomatic self-calibration
ConfigurationDIP switches, PC flash updates, PRO-2 or BluStream
OriginMade in the USA

Installation & setup notes

Order the 7600-DB1 when a work order, parts list or machine manual names that part number. Pyramid confirms it behaves exactly like the 7600-UB1, so the two are interchangeable in any 12V / $1–$100 installation.

Runs on 12VDC from the host machine's harness using pulse or serial (RS-232) output, so it wires to arcade, redemption, gaming and kiosk boards without a separate power supply. Pulse-per-dollar and interface options are set with the on-board DIP switches.

Uses Pyramid's standard bezel footprint; check your cabinet's cutout against the Apex 7000 mounting drawing before ordering.

Related part numbers

  • Same unit under the UB1 part number (no operational difference): Apex 7600-UB1 — $242.50

Not sure this is the right Apex?

The Apex 7000 family shares one validator platform; models differ by power/interface, bezel and denominations. The 7600-DB1 is the 12VDC / Standard Pyramid bezel / $1 – $100 (USD) configuration. Closest alternatives:

  • Need $1 – $20 (USD) instead (denominations)? Choose the Apex 7400-UB1.
  • Need 110VAC (internal power supply) instead (power / interface)? Choose the Apex 7600-UB3.
  • Need Dominican peso (DOP) instead (denominations)? Choose the Apex 7400-UB1-DOM.
